Hyundai WIA HD2200 Turning Center


Overview

The HD2200 CNC turning center, designed by HYUNDAI WIA with years of expertise and the latest technology, is designed to maximize productivity by enhancing both technical performance. All axes of HD2000 are designed with Box Guideway and providing more heavy duty cutting performance.


Machine Features

  • Hyundai Wia Fanuc i series controller
  • 15” (Ø 380mm) Max. turning diameter
  • 22.2” / [21.7”] Turning length
  • Ø2.6” / [Ø3.2”] Bar capacity
  • Powerful 25 HP (18.5kW) spindle motor
  • High torque 260.5 lbf-ft.
  • HD2200C: 297.7 lbf.ft
  • 8” chuck / [10” chuck]
  • RPM 4,000 spindle / [3,500 RPM]
  • A2-6 / [A2-8] spindle nose
  • 45° slanted one-piece bed structure
  • Box guideways
  • 24m/min (944 IPM) X, and 30m/min, (1,181 IPM) Z rapid traverse
  • Manual Tool setter
  • Tool size: □ 1.”/Ø 1.6” (□25mm/Ø40mm)
  • Manual tail stock (Quill Movement Type)
  • 87 PSI coolant system (290 PSI-opt)
  • Spindle override 50% to 150%
  • Massive Meehanite cast iron bed
  • Double Pre-Tensioned Ball screws
  • Rigid tapping
  • Program and data protection key switch
  • Chip Conveyor (42” discharge height)
  • 1 color tower signal light
  • Full enclosure splash guard

Specifications

Max Turning Dia 15"
Max Turning Length 22.2"
Chuck Size 8''
Spindle RPM 4,000
Spindle Horsepower 24.8
Spindle Torque 151.9 ft lbs.
Rapids(X/Z) 944/ 1,181
Travel(X/Z) 8.5"/ 22.8"
No of Tools 12
